ELECTRIC SCISSOR LIFT LGMG MODEL: S1212E

The LGMG S1212EII is a high-performance electric scissor lift designed for both indoor and outdoor use, offering a maximum working height of 14 meters and a platform capacity of 320 kg. With solid non-marking tires, full-height drive, and advanced safety features, it ensures reliable operation and easy maintenance on a wide range of job sites.

Electric Scissor Lift LGMG Model: S1212E

Description

The LGMG S1212EII is a robust and efficient electric scissor lift engineered to meet the needs of modern aerial work applications. It delivers a maximum platform height of 12 meters and a working height of 14 meters, making it ideal for high-reach indoor and outdoor tasks.

This model offers a platform capacity of 320 kg and an additional 120 kg on the extension deck, allowing multiple workers and tools to operate safely and efficiently. The extension deck enhances access to hard-to-reach areas, while the compact overall width of 1.18 meters ensures excellent maneuverability in tight spaces.

Powered by a reliable 24V 300Ah maintenance-free battery, the S1212EII ensures long working hours with minimal downtime. It features solid non-marking tires and front-wheel braking for superior traction and safety.

The machine supports full-height drive, allowing it to move while elevated, and comes equipped with smart safety systems including tilt alarm, descent alarm with flashing beacon, pothole protection, and an intelligent diagnostic system.

Built with universal key components and a swing-out component tray, the S1212EII simplifies maintenance and reduces service time, making it a dependable choice for rental fleets and professional contractors.

Technical Specifications

Platform Height - Raised

12 m

Working Height

14 m

Overall Length

2.49 m

Overall Width

1.18 m

Overall Height - Guardrails Up

2.63 m

Overall Height - Guardrails Down

1.8 m

Extension Deck

0.9 m

Ground Clearance (Stowed / Raised)

100/20 mm

Platform Capacity

320 kg

Platform Capacity - Extension Deck

120 kg

Drive Height

Full Height

Gradeability - Stowed

25%

Turning Radius (Min.)

2.26 m

Raise / Lower Speed

65 s / 60 s

Power Source

24V 300Ah

Tire Size

380x130 mm

Machine Weight

2970 kg

Hydraulic Oil Capacity

23 L

Pricing Information

Rental Rate

SAR 5,500.00 per month
