RENTAL GS-3390 SCISSOR LIFT
The Genie® GS™-3390 rough terrain scissor lift is designed for demanding outdoor worksites, offering exceptional lifting capacity, stability, and drive performance. With a maximum working height of 12.06 m and a large extendable platform, it is ideal for construction, maintenance, and installation applications requiring high reach and heavy load handling.
Equipment Gallery
Description
The Genie® GS™-3390 rough terrain scissor lift is built for tough outdoor jobsites and offers superior performance on uneven surfaces. Designed with a robust four-wheel drive system and a powerful diesel engine, it delivers reliable mobility and gradeability up to 50%.
With a maximum platform height of 10.06 meters (33 ft) and an overall working height of 12.06 meters (39 ft), the GS-3390 provides operators with excellent elevation for construction, maintenance, and installation work. The spacious platform includes optional single or dual slide-out extension decks that can reach up to 6.57 meters (21 ft 6.5 in) in length, offering generous workspace and material capacity.
The lift supports up to 2,500 lb (1,134 kg) and maintains consistent performance even when extended, thanks to its smart load-sensing system. It is equipped with foam-filled rough terrain tires, proportional lift and drive controls, and optional auto-leveling outriggers for added stability and safety.
Additional features include:
- Fold-down guardrails for low stowed height
- Slide-out engine tray for easy maintenance
- Cold weather package, AC generator, and platform air line options
- Telematics support via Lift Connect™ for remote monitoring
Whether on construction sites, industrial yards, or infrastructure projects, the GS-3390 delivers the height, power, and ruggedness needed to get the job done safely and efficiently.
Technical Specifications
Working height max
12060 mm
Platform height max
10060 mm
Platform height - stowed
1550 mm
Platform length - outside
3980 mm
Platform length - extended (single deck)
5340 mm
Platform length - extended (dual deck)
6570 mm
Slide-out extension (front)
1520 mm
Slide-out extension (rear)
1220 mm
Platform width - outside
1830 mm
Stowed height (folding rails)
2710 mm
Stowed height (rails lowered)
2030 mm
Length - stowed
3940 mm
Length - stowed (dual deck)
3980 mm
Length - extended (dual deck)
6570 mm
Width (standard tires)
2340 mm
Wheelbase
2840 mm
Ground clearance
360 mm
Lift capacity
1134 kg
Lift capacity (deck extended)
227 kg
Drive speed - stowed
8 km/h
Drive speed - raised
1.1 km/h
Gradeability
50%
Turning radius (outside)
5330 mm
Fuel tank capacity
75.7 L
Hydraulic tank capacity
113.6 L
Machine weight
5433 kg
