Technical Specifications
Model
T22J (TTZJ)
Work Height Max.
23.8 m
Platform Height
21.8 m
Horizontal Outreach
17.5 m
Below Ground Reach
2.3 m
Platform Length
2.44 m
Platform Width
0.9 m
Platform Capacity
300kg (unrestricted) / 450kg (restricted)
Stowed Length
10.6 m
Overall Width
2.49 m
Stowed Height
2.79 m
Wheelbase
2.51 m
Ground Clearance
0.395 m
Max. Platform Occupants
2 (300kg) / 3 (450kg)
Turntable Rotation
360° continuous
Turntable Tailswing
1.2 m
Drive Speed - Stowed
4.8 km/h
Drive Speed - Raised
0.8 km/h
Gradeability - Stowed
45%
Max. Wind Speed
12.5 m/s
Turning Radius - Inside
2.5 m
Turning Radius - Outside
5.5 m
Max. Slope
4.5°
Drive Mode
"4W Drive
Tires Type
RT Foam-filled
Tires Size
355/55D 625
Power
Deutz D 2.9L4
Fuel Tank Capacity
100 L
Hydraulic Oil Capacity
180 L
Machine Weight
12300 kg
